| Nazwa | Wartość |
|---|---|
| Produkt | Starter |
| Napięcie | 12 V |
| Moc | 4.2 kW |
| Opis | AZF4185 |
| Liczba zębów | 10 |
| Moduł | 3.175 mm |
| Odstęp między zębami | 15.42 mm |
| Zewnętrzna średnica koła zębatego | 39.6 mm |
| Uwagi | With reduction gear |
| Producent | Model | Silnik | Opis | Ltr | Rocznik |
|---|---|---|---|---|---|
| MCCORMICK | Tractors | ||||
| MCCORMICK | Tractors | ||||
| MCCORMICK | Tractors | ||||
| MCCORMICK | X60 X60.50 | 1104D-44TA; 82kW, Tier 3 | 4.4 | ||
| MCCORMICK | X60 X60.50 | 1104D-44TA; 82kW, Tier 3 | 4.4 | ||
| MCCORMICK | X60 X60.50 | 1104D-44TA; 82kW, Tier 3 | 4.4 |
| Pos. | Spare part P/N |
|---|---|
| 1 | 16.285.374 MSX 564 Drive end bracket
|
| 2 | 15.120.243 MSX 684 Bearing
|
| 4 | 16.915.679 MSX 1102 Switch
|
| 6 | 16.902.379 MSX 483 Drive assembly
|
| 7 | 16.907.651 MSX 891 Lever
|
| 8 | 16.904.832 MSX 609 Reduction gear
|
| 9 | 16.908.339 MSX 786 Armature
|
| 10 | 16.908.340 MSX 305 Bearing
|
| 11 | 16.908.542 MSX 236 Fixing parts set
|
| 12 | 16.282.089 MSX 497 Stator
|
| 13 | 16.908.336 MSX 1225 Brush holder
|
| 14 | 16.908.337 MSX 79 Set of brushes
|
| 15 | 16.285.417 MSX 1666 Rear end bracket
|
| Nazwa | Numer oryginalny | |
|---|---|---|
| ARGO | 715630A1 | |
| LETRIKA (ISKRA) | 11.131.709 | |
| LETRIKA (ISKRA) | AZF4185 | |
| LETRIKA (ISKRA) | IS1207 | |
| MAHLE | MS236 | |
| McCORMICK | 715630A1 |
